PALFİNGER JUMBO 900 SERİSİ 90 METRE PLATFORM.
Maksimum 90 metre yüksekliğe çıkabilen kiralık platformumuz maksimum 530 kg kaldırma kapasitesine sahiptir.
 |
Working Height 90m |
 |
Total Weight 48,000 kg |
 |
Cage Dimensions 2.15m x 0.95m x 1.15m |
 |
Platform Height 88m |
 |
Truck Height 4m |
 |
Cage Extension 3.45m x 0.95m x 1.15m |
 |
Lateral Outreach 32.3m |
 |
Truck Length 16.15m |
 |
Cage Capacity 530kg |
 |
Jib Angle +/- 180° |
 |
Siting Inclination 8° |
 |
Cage Rotation +/- 84° |
 |
Wheelbase 8.705m |
 |
MAX Loading 345 kN |
